Features
SmartMC
SmartMC is designed for centralized management of scattered edge devices and simplifies O&M for small and medium campus networks with built-in graphical management. It covers four core capabilities: smart configuration management, intelligent batch O&M & fault replacement, visualized topology monitoring, and one-click user access management. S5570S-EI can serve as the management core to implement unified whole-network control.
Visualization Ability
Supported Telemetry and gRPC protocol enable real-time push of device resources and alarm data to O&M platforms, realizing network quality tracing, risk early warning and architecture optimization to guarantee stable user experience.
High-performance IPv4/IPv6 Service Capabilities
Built on hardware-based IPv4/IPv6 dual-stack platform, the switch supports diverse tunnel technologies, complete Layer 3 routing protocols, multicast and policy routing functions, delivering comprehensive dual-stack network solutions.
H3C Intelligent Resilient Framework 2 (IRF2)
IRF2 virtualizes multiple physical switches into one logical device, bringing multiple advantages. It supports flexible device expansion, plug-and-play deployment and automatic firmware synchronization to lower OPEX. Adopting proprietary routing hot backup technology, it eliminates single-point failure and ensures non-stop Layer 3 forwarding. Distributed link aggregation realizes multi-link load balancing and mutual backup. It uses common service ports for IRF stacking, supporting flexible cross-rack and cross-campus networking.
Comprehensive Security Control Policies
Cooperating with EAD and iMC system, the switch builds proactive and comprehensive network defense. It supports MAC, 802.1X and Portal authentication, as well as multi-element user binding and dynamic VLAN/QoS/ACL policy delivery. It provides high-capacity inbound and outbound ACL and VLAN-based ACL deployment. Integrated uRPF and multi-type attack defense mechanisms effectively prevent source address spoofing, DoS and DDoS attacks.
Multiple Reliability Protection
The switch supports hot-swappable AC/DC dual power modules, with intelligent fan speed adjustment and fault alarm for enhanced hardware reliability. It integrates abundant link-level protection protocols including LACP, STP, Smart Link and RRPP. Combined with IRF2 stacking and ARP defense mechanisms, it supports 1:N redundancy backup, ensures fast network convergence and stable service operation under heavy traffic.
Abundant QoS Features
It supports L2-L4 multi-dimensional traffic classification and three queue scheduling modes: SP, WRR and SP+WRR. It provides precise CAR bandwidth control with a minimum granularity of 16kbps, as well as bidirectional port mirroring, facilitating refined traffic management and network fault troubleshooting.
Outstanding Management Capacity
Equipped with diversified management interfaces, the switch supports CLI, Web, SNMP, Telnet and encrypted SSH 2.0 management, compatible with IMC and mainstream third-party management platforms. It supports local and remote port mirroring, providing abundant traffic analysis tools for network monitoring, data statistics and resource optimization.
Application-Driven Campus
The switch adapts to H3C AD-Campus solution. With open architecture and intelligent capabilities, it simplifies campus network operation, accelerates network convergence, and supports enterprise digital transformation and innovative business deployment.
High Availability
It supports 1+1 hot-swappable redundant power supply, real-time monitoring and alarm for power and fan modules, and temperature-based intelligent fan speed adjustment, ensuring stable hardware operation.
Professional Surge Protection Function
Adopting built-in professional surge protection technology, the switch supports 6KV high surge protection for service ports, effectively reducing equipment damage risks in harsh deployment environments.
Cloud Empowerment, Simplified Network
Compatible with H3C Cloudnet cloud O&M solution, it supports minute-level rapid deployment, zero on-site maintenance, AI intelligent optimization and fault prediction, greatly shortening service launch cycle and improving operational efficiency.
Fast PoE, Perpetual PoE
Fast PoE realizes second-level power supply for terminal devices after switch power-on. Perpetual PoE ensures uninterrupted power supply for PD devices during device hot reboot, guaranteeing continuous terminal operation.
Green Technology
Adopting energy-saving chips and optimized architecture, the switch supports port automatic power-saving and EEE energy-saving mechanisms to reduce idle power consumption. It complies with EU RoHS environmental protection standards, realizing low-power, eco-friendly and low-cost network operation.
